Fuel Flow Data Sheets & Charts

Bill Jones' Photo Gallery Page 29

RBR Home Page

PAGE 1: HILBORN NOZZLE FLOW CHART, at 30psi and .792sg (methanol)-#4 to # 20 Hilborn nozzles----flows at 30 to 90# in 10 # increments

PAGE 2: Setting up a Crower stack fuel injection for gas, 406 drag race at 4200 elevation.-the small details of the 3 bypass cans, the hi-speed relief etc.

#3 is:

Gallons Per Minute (GPM) converted to Pounds Per Hour (PPH)---methanol

-.51 GPM to 6 GPM----202 PPH to 2376 PPH

--------------------------------------------------------------------------

#4 is:

Gallons Per Minute (GPM) converted to Pounds Per Hour (PPH)---methanol

-.01 GPM to .50 GPM---3.96 PPH to 198 PPH---for dealing with idle.

-----------------------------------------------------------------------

#5 is:

499BBC CROWER STACK INJECTION, on gas, for Bonneville

-a basic plan with details of all the components.

-------------------------------------------------------------------------

#6 is:

Square inch area chart of .011" to .164" diameters

-includes references to #4 to #20 Hilborn nozzles, Holley jets, and 5 handy math formulas

-------------------------------------------------------------------------

#7 is:

Total PPH flow of about 12 different sets of eight nozzles----sizes .022: to .040"

-ranges from 225 PPH up to 1065 PPH-----30PSI up to 85psi in 5 pound increments

These files are in .PDF form
